The Pinnacle of Analogue Signal Transfer | Available at Trimira Audio
The Nordost Supreme Reference Odin Gold Analog Interconnects represent the pinnacle of Nordost's analogue signal-transfer engineering, designed for state-of-the-art audio systems where conductor material, dielectric construction, shielding, mechanical control, and termination are all critical.
Odin Gold combines Nordost's Dual Mono-Filament technology, Total Signal Control (TSC) shielding, ultra-pure solid-core OFC conductors with gold plating, mechanically tuned geometry, and proprietary gold-plated HOLO:PLUG® terminations.
At Trimira Audio, we recommend the Odin Gold Analog Interconnects for flagship source components, preamplifiers, integrated amplifiers, and power amplifiers in uncompromising reference systems.
Key Features & Technological Innovations
Pure Gold-Plated Solid-Core OFC Conductors
Odin Gold uses 10 × 23 AWG solid-core conductors manufactured from 99.999999% high-purity Oxygen-Free Copper (OFC) with pure gold plating.
The solid-core construction provides consistent conductor geometry, while gold plating offers excellent resistance to oxidation and long-term surface degradation.
Patented Dual Mono-Filament Technology
Each conductor is wrapped with two helical FEP strands before being enclosed in an extruded FEP outer jacket.
This creates a low-contact dielectric environment designed to minimize dielectric interaction and energy storage while supporting rapid signal propagation.
Total Signal Control (TSC) Shielding
Each individual conductor structure incorporates 100% total-coverage braid/foil shielding, providing extensive protection for delicate analogue signals against:
- Radio-frequency interference
- Electromagnetic interference
- External electrical noise
- Signal-path crosstalk
Mechanically Tuned Lay & Spacing
The conductors are arranged using precisely controlled geometry designed to manage mechanical resonance, microphonic behavior, and electrical interaction throughout the signal path.
Custom Low-Mass Gold HOLO:PLUG® Terminations
Odin Gold is available with custom gold-plated HOLO:PLUG® connectors in:
The XLR configuration is suited to compatible balanced analogue systems.
Technical Specifications
| Specification |
Odin Gold Supreme Reference Analog Interconnect |
| Series |
Supreme Reference Odin Gold Series |
| Insulation |
High-Grade Extruded Fluorinated Ethylene Propylene (FEP) |
| Construction |
Mechanically Tuned Lay, Spacing & Dual Mono-Filament Design |
| Conductors |
10 × 23 AWG Solid-Core |
| Conductor Material |
99.999999% Solid-Core OFC with Pure Gold Plating |
| Capacitance |
18.5 pF/ft (RCA) / 18.5 pF/ft (XLR) |
| Inductance |
0.05 µH/ft |
| Shielding |
100% Total Coverage Individual Total Signal Control (TSC) |
| Velocity of Propagation |
90% Speed of Light |
| Termination Options |
Custom Gold HOLO:PLUG® RCA or Gold HOLO:PLUG® 3-Pin XLR |
| Standard Lengths |
0.6 m, 1.0 m, 1.5 m, 2.0 m, 2.5 m, 3.0 m, 4.0 m, 5.0 m + Custom Lengths |
RCA vs XLR Configuration
RCA
The single-ended RCA configuration is suitable for conventional analogue connections between compatible source and amplification components.
XLR
The balanced 3-pin XLR configuration is designed for systems where both connected components support a genuine balanced analogue signal path.
Trimira Audio can assist in determining the appropriate termination based on the actual architecture of your equipment.
Consult with the Audio Specialists at Trimira Audio
The Nordost Supreme Reference Odin Gold Analog Interconnects are intended for reference systems where the analogue signal path is engineered without compromise.
Trimira Audio can assist with:
- RCA versus XLR selection
- Cable length selection
- Source-to-preamplifier matching
- Preamplifier-to-amplifier connections
- Complete Nordost reference cable-system planning
- Private system auditions
For Nordost's pinnacle analogue interconnect architecture, Odin Gold combines 23 AWG gold-plated solid-core OFC, Dual Mono-Filament FEP construction, 100% TSC shielding, mechanically tuned geometry, and gold-plated HOLO:PLUG® termination options.
