Lohengrin Reference Monoblock

$157,995
$157,995
Taxes included.
Vendor: VTL
View full details
Lohengrin Reference Monoblock
Lohengrin Reference Monoblock

$157,995

VTL

Lohengrin Reference Monoblock

*This product is built to order. The estimated delivery time is 3 months.

Since the introduction of the Siegfried Reference monoblock and the S-400 Reference Stereo amplifiers, VTL has been widely recognized as the leader in the world of reliable, high powered, high performance amplifiers, both for musicality and ease of use. Known as the first tube amplifier to deploy true Auto Bias and Fault Sensing, as well as precision-regulated power supply technology, our Reference amplifiers have won the loyalty and appreciation of serious music lovers around the world.

With the introduction of the Lohengrin Reference monoblock amplifier, VTL is pushing the boundaries of high power tube amplification to a new frontier. Lohengrin is more than just a new amplifier; it demonstrates VTL’s ongoing commitment and passion for audio excellence, establishing a new benchmark for musicality and sonic realism. Developed through five years of dedicated research and refinement, Lohengrin embodies VTL’s extensive accumulation of knowledge and deep understanding of the technologies essential to lifelike, realistic music reproduction. Our guiding passion is to craft an amplifier that illuminates the music, drawing listeners closer to the essence of the artist’s intention.

Renowned for modern-sounding designs that balance formidable power with harmonic opulence and intuitive ease of use, VTL amplifiers have long been celebrated for their ability to deliver speed, finesse, and musical agility typically associated with lower-powered amplifiers. With Lohengrin, these often-elusive qualities are elevated a new level.

The Lohengrin amplifier features an eight-tube output stage configuration capable of delivering 400 watts, retaining the higher-powered Siegfried amplifier’s driver stages and power supply. By employing tubes—easier to drive than transistors and free from the “current hogging” issues common in parallel designs—the Lohengrin amplifier achieves an ideal balance of power and responsiveness. Its innovative technologies produce a lower output impedance, reducing the necessary step-down to the loudspeaker load and enabling a simpler, more effective output transformer.

Our Precision-regulated power supplies hold the output tubes at optimal operating points even under demanding loads. Our wide-bandwidth, heavily interleaved multi-section output transformers ensure seamless, grain-free extension into the upper frequencies. Lohengrin’s zero global negative feedback design, broad audio bandwidth (-1dB at 100kHz), and adjustable damping factor provide capability and flexibility for tailoring to the speaker load and listener’s preference.

The amplifier’s user interface makes tube operation intuitive and worry-free. Fully automatic bias control and comprehensive, multi-layered fault-sensing systems enhance reliability and simplify the management of the output tubes. Fully bi-directional RS-232 interface provides control and diagnostic information.

Musically, the tonal spectrum of the Lohengrin is seamlessly integrated from top to bottom, the soundstage is precise and expansive, revealing the venue where the musicians perform with astonishing realism. Lohengrin reveals micro dynamics – those subtle dynamic shifts musicians use to express beauty and emotion – with nuanced alacrity. Bass instruments are presented with linearity, definition and control. True to its heritage, Lohengrin presents the weight and authority of the original event with grace and power. The sound is fresh, vibrant, and immersive, drawing listeners deeply into the music.

Building upon our signature foundation of dynamically expressive, authoritative sound, Lohengrin delivers extraordinary immediacy, drawing listeners inward, beyond mere sonic accuracy, toward something subtler and truer: the hidden intentions, elusive emotions, and unspoken truths musicians strive to convey.

Specifications

Feature Specification
Vacuum Tube Complement 1 x 12AT7, 2 x 12BH7, 8 x 6550 or KT-88

Output Power


(20Hz – 20kHz, into 5Ω load)

Tetrode: 400W


Triode: 200W

Total Harmonic Distortion (T.H.D.)


(20Hz – 20kHz)

Tetrode (@ 400W): < 2.5%


Triode (@ 200W): < 2.5%

Inputs 1 x Balanced XLR, 1 x Single-ended RCA
Outputs 1 pair 5-way Binding Posts
Class of Operation AB1
Optimal Load Range 4 – 8 Ω
Input Sensitivity Variable between 1.0V – 2.0V, depending upon DF (Damping Factor) setting
Input Impedance 47kΩ
Balanced Input CMRR 60 dB

Signal-to-Noise Ratio (S/N)


(At full rated power)

-110dB @ 120Hz (Tetrode and Triode)
Power Consumption

Idle: 350W


Full Power: 900W

Secondary DC Fuse Ratings

Plate: 4A Fast 600V


Screen: 0.75A Fast 600V

Primary AC Fuse Ratings

Logic: 1A Slo Blo (120V / 220V / 240V)


B+: 15A Slo Blo (120V) / 8A Slo Blo (240V)


Input: 2A Slo Blo (120V) / 1A Slo Blo (240V)


Filament: 2A Slo Blo (120V) / 1A Slo Blo (240V)

Dimensions (W x D x H) 11.5 x 19.25 x 19.5 inches (29 x 49 x 50 cm)
Weight

Net Weight: 170 lbs (77 kg) per unit


Shipping Weight: 500 lbs (227 kg) (pair packed in one crate)
