JL Audio

JL Audio Fathom® 8-inch (200 mm) In-Ceiling Powered Subwoofer System (IWICE-SYS-208)

In-Ceiling Subwoofer System with Single 8-inch Subwoofer, 300 watts

Created from the same innovative technologies used to develop our free-standing powered subwoofers, the Fathom® ICS in-ceiling subwoofer systems are engineered to deliver outstanding bass performance, with nearly unlimited placement freedom. Purpose-built to disappear into the ceilings of most home audio/theater environments, the 8-inch Fathom® ICS systems are designed to fit 2" x 6" or larger ceiling joists and a wide range of assembled joist widths, while operating through very small grilles. The grille’s clever design accommodates all common drywall thicknesses and can be easily painted to match a room’s decor.

The subwoofer enclosures utilize extensive architectural features aimed at improving rigidity while keeping a very low profile and minimal wall thickness. A unique port design vents through a slot located at the perimeter of the driver mount to enhance efficiency and low-bass output. Inside the enclosure is a long-excursion, 8-inch thin-line woofer, built to exacting standards by JL Audio for the Fathom® ICS products. Each 8-inch Fathom® ICS system is driven by a rack-mountable amplifier with up to 600 watts of clean power, programmed specifically for each system, and capable of driving up to two enclosures. A complete set of Fathom® signal processing features is also onboard, including our powerful, 18-band Digital Automatic Room Optimization (D.A.R.O.) system, and high-pass crossover outputs, all accessible via an easy-to-use, menu-driven interface and LCD display. Note: D.A.R.O. functionality requires optional calibration microphone (sold separately).

The ICS-108 System fits 2" x 6" ceiling joists or larger, with assembled joists ranging from 16-inches to 25 1/2-inches on center. Consult your Authorized JL Audio Dealer for specific application information.

Features

Enclosure Finish: Flat Black (hidden from view when installed)
Grille finish: Primer White (paintable)
Enclosure Construction: CNC-Cut Birch Plywood

System Components
1 x IWICE-108 enclosures with 8-inch woofer
1 x IWG-108 speaker grille
1 x SA-600 300W/600W amplifier/processor

• Driver: Dual 8-inch (200 mm) drivers.
• Enclosure Type: Ported, with a black texture-coated finish.
• Frequency Response: 24.9 Hz - 109 Hz (± 1.5 dB) (anechoic).
• Effective Piston Area (Sd): 63.24 sq in / 0.0408 sq m.
• Effective Displacement: 95.0 cu in / 1.56 L.
• Input Grounding: Isolated or Grounded
• Speaker Outputs: Neutrik speak-On® 2-Pole Connectors (uses Neutrik part: NL2FX, included).
