dCS LINA DAC
dCS LINA DAC

$22,000

dCS

LINA DAC

Simple, elegant and exceptionally musical systems can be designed with a small footprint if desired. Connect the DAC to an integrated, pre + power, direct to power amp or active speakers and use the dCS Mosaic app to control volume, access music and all settings.

Features

A New Beginning Built on a Long History of DAC Technology

The Lina Network DAC is both a continuation and a new beginning. Its design combines renowned dCS technologies with new innovations developed for headphone listeners, resulting in a bold new interpretation of the dCS experience, and a complete reimagining of form and function.

With the Lina Network Streaming DAC, dCS has taken core playback technologies, including the dCS Ring DAC™ and Digital Processing Platform, and added new innovations developed for headphone listeners. These include their first ever touch-screen display, a streamlined user interface for easier navigation, and a powerful flex-rigid circuit board which allows for the delivery of all the features you’d expect from a dCS DAC but in a much smaller chassis.

Stunning Results

The result is a powerful, supremely capable product designed for use in a wide range of environments, from living rooms to studios and workspaces. With its wide dynamic range, crisp and clear playback, expansive soundstage, and tonal neutrality, it provides a deeply natural, highly detailed, and profoundly musical sound that encapsulates dCS' singular approach to audio.

Add unique headphone optimization technology, an elegant and tactile design, and a high-performance streaming platform, and you have a hugely versatile source that delivers spectacular sound however you choose to listen. Designed to inspire, inform and entertain, it will give you a whole new perspective on the artists and recordings you love.

  • dCS Ring DAC technology with ultra-black background
  • Elevate any headphone or two channel system
  • Network streaming with the dCS Mosaic platform - supports Hi-Res streaming via Roon, Spotify, TIDAL, UPnP, and more!
  • Now available in Black and Silver finishes
  • Dimensions: 4.78" (H) x 8.66" (W) x 13.35" (D) (121.5mm x 220mm x 339mm)
  • Weight: 16.3 lbs (7.4kg)
  • Finish: Black or Silver machined aluminum with crystal LED display
  • Network Interface: RJ-45 ethernet
  • Electronics
    • dCS Ring DAC and Digital Processing Platform on flex ridged PCB
    • Stream Unlimited S800
    • Automatic voltage switching
  • Digital Inputs
    • (x2) AES/EBU on 3 pin XLR 44.1-384kS/s
    • (x1) S/PDIF BNC Coax 44.1-192kS/s
    • (x1) S/PDIF on RCA 44.1-192kS/s
    • (x1) Toslink 44.1-96kS/s
    • (x1) USB Type B 44.1-384kS/s, PCM and DSD, DSDx2 in Async Mode
    • (x1) USB Type A connector for mass storage devices (navigated using Mosaic)
  • Streaming Compatibility
    • UPnP
    • Qobuz
    • Deezer
    • Tidal
    • Internet Radio
    • Spotify
    • Apple AirPlay 2 (support at 44.1 or 48kS/s)
    • RoonReady
  • Sample frequencies and formats
    • 44.1-384kHz
    • DSD 64, 128
    • Native DSD + DoP (input dependent)
    • FLAC, WAV, AIFF, MQA
  • Analog Outputs
    • (x1) Stereo pair 3 pin Balanced XLR
    • (x1) Stereo pair RCA
  • Upsampling
    • Multi-stage DXD oversampling with switchable DSD
    • Will clock to 44.1-192kHz
  • Word Clock: (x2) Word Clock inputs on 75 Ω BNC connectors
  • Filters
    • PCM mode: 2 filters + MQA
    • DSD mode: 4 progressive filters
  • Crossfeed Settings
    • Standard crossfeed
    • dCS Enhanced crossfeed (E1)
    • dCS Enhanced crossfeed (E2)
  • Power
    • IEC inlet & power switch on rear panel
    • 90-120v & 220-240v, 50/60Hz nominal
    • Automatic voltage switching
  • Power Link (on/off synchronization across other components): (x2) RJ45
  • Frequency Response (on filter 1)
    • Fs = 44.1 or 48kS/s +/-0.1dB, 10Hz-20kHz
    • Fs = 88.2 or 96kS/s +/-0.1dB, 10Hz-20kHz -3dB @ >38kHz
    • Fs = 176.4 or 192kS/s +/-0.1dB, 10Hz-20kHz -3dB @ >67kHz
    • Fs = 352.8 or 384kS/s +/-0.1dB, 10Hz-20kHz -3dB @ >100kHz
    • DSD64 +/-0.1dB, 10Hz-20kHz -3dB @ >90kHz
    • DSD128 +/-0.1dB, 10Hz-20kHz -3dB @ >100kHz
  • Residual Noise (6v output)
    • 16-bit data: Better than –96dB0, 20Hz-20kHz unweighted
    • 24-bit data: Better than –113dB0, 20Hz-20kHz unweighted
  • Spurious Response: Better than –105dB0, 20Hz-20kHz
  • L-R Crosstalk: Better than –115dB0, 20Hz-20kHz

"As a team, the Lina Network DAC and Lina Master Clock provide an insight into the textures of microdynamic structures, timbres and melodies, sharpness and depth…"
