Reference-Grade Cinematic Nerve Center & HDMI 2.1 Processing | Available at Trimira Audio
Engineered and crafted in Canada, the Anthem AVM 70 8K AV Processor serves as the nerve center for state-of-the-art reference home cinema installations. Delivering 15.2 channels of discrete preamplifier processing with dual independent subwoofer outputs, the AVM 70 8K seamlessly handles high-density immersive audio layouts—including up to 9.2.6 or 7.2.4 Dolby Atmos and DTS:X Pro speaker configurations—with absolute signal purity and micro-detail retrieval.
This updated 8K edition integrates an advanced HDMI 2.1 matrix switching platform, offering 7 dedicated 8K/60Hz and 4K/120Hz inputs supporting HDCP 2.3, HDR10+, Dolby Vision, and eARC. Powered by 32-bit/768 kHz audiophile DACs and an internally shielded toroidal power supply, the AVM 70 8K achieves a ultra-low -100 dB THD+N rating. Outfitted with Anthem's industry-leading ARC™ Genesis room correction system (calibrated professional microphone included), it calibrates frequency response, phase alignment, and subwoofer delay to overcome acoustic room anomalies.
Key Features & Technological Innovations
-
15.2 Discrete Channel Processing: Full pre-outs for up to 15 speakers and 2 independently tuned subwoofers across balanced XLR and single-ended RCA outputs.
-
HDMI 2.1 & 8K Video Platform: 7 inputs and 3 outputs supporting 8K/60Hz and 4K/120Hz pass-through, ALLM, VRR, Dynamic HDR, and eARC.
-
ARC™ Genesis Room Correction: Includes a calibrated measurement microphone to correct acoustic boundary loading, standing waves, and crossover timing.
-
Immersive Object-Based Audio: Supports Dolby Atmos, DTS:X, DTS:X Pro, DTS Virtual:X, and IMAX Enhanced decoding modes.
-
Audiophile DAC Architecture: High-resolution 32-bit/768 kHz digital-to-analogue conversion delivers a pristine 110 dB signal-to-noise ratio.
-
Universal Wireless Streaming & Control: Native integration for Apple AirPlay 2, Google Chromecast Audio, Spotify Connect, Roon, and Bluetooth v4.2.
-
Dedicated Moving Magnet (MM) Phono Stage: Low-noise internal phono preamp allows direct connection of high-end analogue turntables.
-
Advanced Custom Integration Control: Intuitive web-browser user interface, Anthem Remote App, and full IP driver support for Control4, Crestron, Savant, and ELAN.
Technical Specifications
-
Processing Channel Count: 15.2 Channels (17 Discrete Processed Channels including 2 Independent Subwoofers)
-
Digital-to-Analogue Converters (DAC): 32-Bit / 768 kHz
-
Frequency Response: 20 Hz – 35 kHz (+/- 0.2 dB)
-
Frequency Response (Analogue-Direct): 20 Hz – 80 kHz (+0, -2 dB)
-
Total Harmonic Distortion (THD+N): -100 dB @ 4 Vrms output
-
Signal-to-Noise Ratio (SNR): 110 dB (IEC-A filter @ 4 Vrms output)
-
Maximum Output: 10.7 Vrms (XLR Outputs), 11 Vrms (Subwoofer Outputs)
-
Surround Decoding Formats: Dolby Atmos, DTS:X, DTS:X Pro, IMAX Enhanced, DTS Virtual:X
-
HDMI Video Platform: HDMI 2.1, HDCP 2.3 (8K/60Hz, 4K/120Hz, Dynamic HDR, Dolby Vision, eARC)
-
HDMI Inputs / Outputs: 7 x HDMI Inputs, 3 x HDMI Outputs (Main eARC, Zone 2)
-
Analogue Inputs: 4 x RCA Stereo Pairs, 1 x Moving Magnet (MM) Phono Input
-
Digital Inputs: 3 x TOSLINK Optical, 2 x Coaxial SPDIF
-
Analogue Audio Outputs: 15.2 Channel Balanced XLR Pre-outs, 15.2 Channel Unbalanced RCA Pre-outs, Zone 2 RCA
-
Network / Control: Ethernet, Wi-Fi, 12V Trigger In/Out, RS-232, IP Control
-
Dimensions (H x W x D): 15.24 cm x 43.18 cm x 36.4 cm (4U Rack Height)
-
Net Weight: 10.1 kg (22.2 lbs)
Consult with the Custom AV Specialists at Trimira Audio
Build your ultimate multi-channel cinema surrounding the Anthem AVM 70 8K. Contact the home theatre and custom integration specialists at Trimira Audio in Brisbane to discuss power amplifier pairing (such as the Anthem MCA series), ARC Genesis room calibration, or to schedule a private audition.
