Description

Accuphase

DP-750 Precision MDSD SA-CD Player

Quiet and ultra-smooth disc loading mechanism combined with a high-rigidity, high-precision SA-CD/CD drive extracts the full scope of the recorded information. The innovative MDSD (Multiple Double Speed DSD) D/A converter comprises eight MDS++ devices driven in parallel and a moving average filter to recreate an analog signal of stunning purity. The versatile array of transport outputs and digital inputs enables connection of a voicing equalizer or other equipment in the digital domain. Harnessing the latest technology in a masterful ensemble, the DP-750 goes straight to the heart of the music.

  • High-grade SA-CD/CD drive
  • MDSD type D/A converter using eight parallel devices
  • Support for playback of data discs (CD-R/-RW, DVD-R/-RW/+R/+RW)
  • Direct Balanced Filter with separate line and balanced signal paths
  • HS-LINK and USB digital interfaces
  • Transport outputs and digital inputs allow insertion of DG-58 into signal path for sound field correction
  • Phase selector for balanced outputs
  • Numeric indication of sampling frequency and quantization bits






Specification


Transport Section
Compatible Disc Format

2-channel Super Audio CD
CD
DSD Disc DVD-R/-RW/+R/+RW (DSF File Format)
Data Disc CD-R/-RW, DVD-R/-RW/+R/+RW
(Supported Formats: WAV, FLAC, DSF, DSDIFF)


Data Read Principle



Non-contact optical pickup
Laser Diode Wavelength
 SA-CD 655 nm
CD 790 nm


Transport Outputs
 Output Format Suitable Cable
HS-LINK Proprietary Standard Dedicated HS-LINK Cable
OPTICAL
 JEITA CP-1212 Compliant
 JEITA Standard Optical Fiber Cable
COAXIAL IEC 60958 Compliant 75-ohm coaxial digital cable
Digital Processor Section
 Digital Inputs
 Input Format Suitable Cable
HS-LINK Proprietary Standard Dedicated HS-LINK Cable
USB USB 2.0 Hi-Speed (480Mbps) compliant USB 2.0 Cable with Type B connector
OPTICAL JEITA CP-1212 compliant JEITA standard optical fiber cable
COAXIAL IEC 60958 compliant 75-ohm coaxial digital cable
Supplied Accessories
  • AC Power Cord
  • Audio cable with plugs ASL-10
  • Remote Commander RC-120
  • USB Utility 3 CD
  • USB Utility 3 Setup Guide
  • Cleaning cloth
Sampling Frequencies
 Input Format Suitable Cable Number of bits
HS-LINK (Ver.1)
 DSD
PCM
2.8224MHz
32/44.1/48/88.2/96/176.4/192kHz
1
16 to 24

HS-LINK (Ver.2)
DSD
PCM
2.8224MHz / 5.6448MHz
32/44.1/48/88.2/96/176.4/192/352.8/384kHz
1
16to32
USB
DSD
PCM
2.8224/5.6448MHz
44.1/48/88.2/96/176.4/192/352.8/384kHz
1
16 to 32
COAXIAL
PCM
PCM
32/44.1/48/88.2/96kHz
32/44.1/48/88.2/96/176.4/192kHz
16 to 24
16 to 24
D/A Converter
 D/A converter CD playback and external input (PCM) 8MDS++ type
SA_CD playback and external input (DSD) 8MDSD type
Frequency Response
0.5 to 50,000Hz +0,-3.0dB
THD + Noise  0.0005% (20 to 20,000Hz)
Signal-to-Noise Ratio 120dB
Dynamic Range  117dB
Channel Separation 118dB (20, to 20,000Hz)
Output Voltage and Impedance
BALANCED 2.5V 50ohms, balanced XLR type
LINE 2.5V 50ohms, RCA phono jack
Output Level Control 0dB to -80dB in 1-dB steps (digital)
General
Power Requirement  DVD-R/-RW/+R/+RW (DSF file format)
Power Consumption 26W
Maximum Dimensions


Width 477mm (18.8'')

Height 156mm (6.1'')

Depth 394mm (15.5'')
Mass


28.2kg (62.2lbs) net

35.0kg (77.2 lbs) in shipping carton
