Accuphase

DP-430 MDS Compact Disc Player

The Accuphase-developed high-rigidity, high-precision drive optimized for CD reproduction, along with a super-quiet and smooth disc loading mechanism ensure pure signal readout of the highest order. In the processor section, the MDS type D/A converter utilizes four DAC chips driven in parallel, and the filter amplifier features the newly developed ANCC (Accuphase Noise and Distortion Cancelling Circuit). CD transport section and digital processor are kept completely separate. In addition to a USB input, coaxial and optical connectors are provided for digital input and transport output. Quality construction and highly advanced digital technology fully reveal the potential of the CD medium and provide a listening experience that opens up new emotional depths even with familiar music sources.

  • High-precision CD drive.
  • High-quality CD tray and ultra quiet and smooth loading mechanism.
  • MDS D/A converter with four circuits driven in parallel.
  • Direct Balanced Filter with separate line and balanced signal paths.
  • Phase selector for balanced outputs.
  • Digital interface with USB input.
  • Transport outputs and digital inputs allow insertion of DG-58 into signal path for sound field correction.
  • Sampling frequency and quantization bit display.





Transport Section
Format
 Standard CD Format
 Quantization 16 bits
Sampling Frequencies 44.1 kHz
Error Correction Principle CIRC
Number of channels 2
Revolution SPeed 500 to 200 rpm (CLV)
Scan Velocity 1.2 to 1.4 m/s, constant
Data Read Principle


Non-contact optical pickup

Laser Diode Wavelength

GaAIAs (double hetero-junction visible-spectrum semiconductor laser diode)

Wavelength: 667nm

Transport Outputs
COAXIAL Format IEC 60958 compliant
OPTICAL
Format JEITA CP-1212 compliant
Digital Processor Section
Digital
Inputs
COAXIAL
 Format
Suitable Cable
IEC 60958 AES-3 compliant
75-ohm coaxial digital cable
OPTICAL
Format
Suitable Cable
JEITA CP-1212 compliant
JEITA Standard optical fiber cable
USB
Format
Suitable
cable
 USB 2.0 HI-speed
(480 Mbps) compliant
USB 2.0 cable
Sampling Frequencies
COAXIAL 32kHz to 192kHz (16 to 24 bits
OPTICAL 32kHz to 96kHz (16 to 24 bits, 2-channel PCM)
USB

32kHz to 384kHz (16 to 384kHz (16 to 32 bits, 2-channel PCM)
2.8224MHz, 5.6448MHz, 11.2896MHz
(1-bit 2-channel DSD) (11.2896MHz: ASIO only)

D/A Converter 4MDS Principle
Frequency Response 0.7 to 50,000Hz   +0,-3.0 dB
Total Harmonic Distortion 0.0008% (20 to 20,000Hz)
Signal-to-Noise Ratio 117dB
Dynamic Range 113dB
Channel Seperation 113dB
Output Voltage and Impedance
 BALANCED 2.5V, 50ohms, balance XLR type
LINE 2.5 V, 50ohms, RCA phono jack
Output Level Control 0dB to -60.0dB in 1-dB steps (digital)
General
Power Requirements 120/220/230V AC, 50/60Hz (voltage as indicated on rear panel)
Power Consumption 13W
Max. DImension

Width: 465mm (18.3'')

Height: 151mm (5.9'')

Depth: 393mm (15.5'')

Mass

14.0kg (30.9lbs) net

20.0kg (44.1lbs) in shipping carton

Supplied Accessories
  • Remote Commander RC-130
  • AC Power Cord
  • Audio Cable with plugs AL-10
  • USB Utility 2 CD
  • USB Utility 2 Setup Guide
